These slim-yet-mighty subwoofers pack a big punch – delivering maximum low-frequency output in a shallow space. The ultimate solution for deep, rich bass in a sleek and slim design.
The fiber matrix injection molded polypropylene cone ensures that every note is reproduced to perfection, so you can feel the bass hit. The 3-layer high temp voice coil former means they can handle even the most intense bass without breaking a sweat. And don’t worry about distortion ruining your jams – these subwoofers feature an optimal thermal efficiency design to ensure that your bass stays clean and clear. Not only do these subwoofers sound amazing, they’re also built tough. With their weather-resistant design and removable grille you can enjoy your music even if your vehicle likes to play off-road.
features
- Low-Profile Shallow Mount Subwoofer
- Fiber Matrix Injection Molded Polypropylene Cone
- Weather-Resistant Design
- 3-Layer High Temp Voice Coil Former
- Optimal Thermal Efficiency
- Wrap-Sealed Rubber Gasket to Protect Enclosure Interior
- Removable Subwoofer Grille Included
specifications
thiele/small parameters
Nominal Impedance (Z) 4 ohms
DC Resistance (Re) ]] 3.2 ohms
Resonance Frequency (Fs) 37.3460 Hz
Piston Area (Sd) 0.0330 m2
Force Factor (BL) 14.0082 T.m
Mechanical Q Factor (Qms) 2.8618
Electrical Q Factor (Qes) 0.4044
Total Q Factor (Qts) 0.3543
Sensitivity 1W/M (SPL) 87.2957
Mechanical Comp (Cms) 0.1719 mm/N
Moving Mass (Mms) 105.6787 g
Linear Excursion (Xmax) . 9 mm
Volume Acoustic Comp (Vas) 26.1432 Ltr/0.923238 cu ft
Reference Efficiency (NO.) 0.32% RMS
Power (Pe) 400 Watts
Frequency Response 20-250 Hz
Voice Coil Diameter 2.5 in/63.5 mm
Displacement 0.045 cu ft/ 1.275 Ltr
in the box:
SPC-10S2, Manual, Warranty
dimensions
- Overall Dimensions: 10.39 in/ 264 mm
- Cut Out Diameter: 9.13 in/ 232 mm
- Mounting Depth: 3.5 in/ 89 mm
- Mounting Height (w/o Grille): 0.71in / 18mm
- Mounting Height (w/ Grille): 1.22 in / 31mm
ported enclosure
- External Dimensions: 24.00″ W × 14.50″H × 12″D
- Net Internal Volume: 1.40 ft3
- Total Internal Volume: 1.75 ft3
- Gross External Volume: 2.38 ft3
- Material Thickness: 0.75″
- Tuning Frequency: 40 Hz
- Port Area” 22.75 inch2
- Port Inlet: 1.75″W× 13″H
- Port Length: 22.25″
- F3 (Hz): 34
sealed enclosure
- External Dimensions: 26″ W × 14.50″H × 5.00″D
- Net Internal Volume: 0.60 ft3
- Total Internal Volume: 0.65 ft3
- Gross External Volume: 1.09 ft3
- Material Thickness: 0.75″
- F3 (Hz): 60
- Qtc: 0.703
*Enclosure size recommendations do not include driver and/or port displacement
